Shaft length (LTotal)
3, 4.5 mm
Number of shafts (NShaft)
2
Shaft pitch (PShaft)
600 µm
Shaft width (WShaft)
51 µm
Number of electrodes (NEl)
16 (2 x 8)
Electrode Pitch (PEl)
50 µm
Electrode Length (LEl)
350 µm
Electrode size (DEl), material (EM), probe thickness (T)
25 µm, IrOx, 50 µm
Size of the optional, internal reference electrode
42 × 100 µm2
