Shaft length (LTotal)
2 mm
Number of shafts (NShaft)
8
Shaft pitch (PShaft)
200 µm
Shaft width (WShaft)
60 µm
Number of electrodes (NEl)
32 (8 x 4)
Electrode Pitch (PEl)
100 µm
Electrode Length (LEl)
300 µm
Electrode size (DEl), material (EM), probe thickness (T)
Ø 35 µm, Pt, 100 µm
Size of the optional, internal reference electrode
