Shaft length (LTotal)
25 mm
Number of shafts (NShaft)
1
Shaft width (WShaft)
160 µm
Number of electrodes (NEl)
32 (7 tetrodes, 3 electrodes, 1 reference electrode)
Electrode Pitch (PEl)
275 µm for tetrodes
Electrode Length (LEl)
2475 µm
Electrode size (DEl), material (EM), probe thickness (T)
Ø 25 µm IrOx, 50 µm
Size of the optional, internal reference electrode
