Shaft length (LTotal)
1.5 mm
Number of shafts (NShaft)
4
Shaft pitch (PShaft)
200 µm
Shaft width (WShaft)
75 µm
Number of electrodes (NEl)
64 (4 x 16)
Electrode Pitch (PEl)
50 µm
Electrode Length (LEl)
750 µm
Electrode size (DEl), material (EM), probe thickness (T)
25 µm, IrOx, 50 µm
Size of the optional, internal reference electrode
